Hydraulic Pallet Stacker
Product Code : FIE 111
Brand Name : FUTURE INDUSTRIES
We have gained immense recognition in the industry by offering a quality assured range of Hydraulic Pallet Stacker. This stacker is manufactured by utilizing modern technology and optimum quality raw materials under the supervision of our deft professionals as per the predefined industry quality standards. The offered stacker is ideal for carrying and lifting heavy products from one side to another. Our valuable clients can avail this Hydraulic Pallet Stacker in various specifications as per their diverse requirements at reasonable prices.
- Our stackers have high load bearing capacity, hence these are preferred by various industries
- These stackers are appreciated for their unmatched performance and are fitted with wheels for easy transportation
- Offered stackers have user-friendly design, which makes it very easy to use
- Corrosion & rust proof surface finish and longer service life of these stackers has been acknowledged
- Remote power pack with 4 mtr Hydraulic Hose.
- Push button control on 3.5 mtr cable.
- Hydraulic pump with built in overload relief.
- Full length deck beam for maximum support.
- Solid plate scissor legs for maximum rigidity.
- Chequered Plate deck and lip with chain.
- All pivot points equipped with lubricated nipples.
- Lowering brake valve to prevent platform free fall.
- Completely sealed, weather resistant glinders and piston.
- Motor, controls, push button factory pre wired and tested.
- Capacity: 500kgs to 2ton
- Fork length: 1150mm/as per customer requirement
- Fork width: 600mm/as per customer requirement
- Fork: 150mm
- Lower height: 85mm
- Raised height: 1600mm/1800mm/2000mm/2500mm/3000mm/as per customer requirement
- Mast system : single/double mast system
- Lower speed: continuously variable
- Pump : simple and reliable hydraulic system
- Wheels: dust free nylon wheels with double sealed bearings.
- Wheels steering and support wheels : 2 nylon wheels 180 x 50mm
- Load wheels : 4 nylon wheels 80 x 70mm
- color: golden yellow powder coated color
- Handle : draw bar with finger protection clamp and release handle
- Structure: simplex single mast structure made from heavy duty channel section. It would be supported by heavy-duty deep grooved guide rollers. Forks lifting would be by means of 2 nos. Duplex chain & design pulley.
- Hydraulic unit : hydraulic cylinder part would be supported by single acting cylinder piston rod is inducted with hard chrome plated. The sealing arrangement is of polyurethane seals, PTFE seals for long life smooth working. Leak proof viper seals will be given to protect from ingress dirt & dust.
- Hydraulic electric power pack unit (optional)
- M/s oil tank 25 litres. (w/o oil) 1nos
- Gear pump 1nos
- Pressure gauge 1nos
- Pressure relief valve 1nos
- Many fold block 1nos
- Suction filters 1nos
- A. C electric solenoid valve 1nos
- Pilot operated check valve 1nos
- Phase a. C motor 1nos
- Flow control valve 1nos
- Completed fitting accessory 1nos
- Height safety control: limit switch for height safety control.
- Cable : 3meter standard length cable
- Silent in operation
- Easy to operate
- Light and manoeuvrable
- Minimum maintenance
