+919909708085With our rich industry experience, we manufacture, export and supply a supreme quality range of Battery Operated Pallet Truck. The offered pallet truck is manufactured under the guidance of our talented professionals by utilizing premium grade raw material and advanced technology in adherence with defined quality standards. This pallet truck is used in various industries for carrying heavy goods from one place to another. Also, this product can get from us in different specifications as per the diversified need of our clients at market leading prices.
Battery Operated Pallet Truck Advantages:
Battery Operated Pallet Truck Technical Specifications:
Model No. |
| FIE-108 |
Drive Unit |
| Battery |
Operator Type |
| Walkie |
Load Capacity | Q(kg) | 2200 |
Load Center | C (mm) | 600 |
Load Distance (Raised) | X(mm) | 883/946 |
Wheelbase | Y(mm) | 1250 |
Weights |
|
|
Service Weight (Incl. battery) | kg | 195 |
Axle loading, laden operator/load side | kg | 600/1095 |
Axle loading, unladen operator/load side | kg | 170/25 |
Wheels, Chasis |
|
|
Tyre Type |
| PU |
Tyre size, operator side |
| 210 x 70 |
Tyre size, load side |
| 80 x 60 |
Wheels, number operator/load side (x=drive wheels) |
| 1 x /4 |
Tread, Load Side | b11 (mm) | 380 |
Dimensions |
|
|
Lift Height | h3(mm) | 115 |
Height of tilter arm in operating position, min/max | h14 (mm) | 820/1170 |
Fork height, lowered | h13 (mm) | 90 |
Overall length | l1 (mm) | 1600 |
Length to face of forks | l2 (mm) | 450 |
Overall Width | b1/b2 (mm) | 560 |
Fork Dimensions | s/e/l (mm) | 55/150/1150 |
Fork spread, min/max | b6 (mm) | 560 |
Ground clearance, center of wheelbase | m2 (mm) | 35 |
Aisle width, 1000 x1200 pallet crossways | Ast (mm) | 1779 |
Aisle width, 800 x1200 pallet lengthways | Ast (mm) | 1929 |
Turning radius | Wa (mm) | 1475 |
Performance |
|
|
Travel speed, laden/unladen | km/h | 3.5/4 |
Lifting speed, laden/unladen | m/s | 0.051/0.060 |
Lowering speed, laden/unladen | m/s | 0.052/0.059 |
Maximum gradeability, laden/unladen s2 5min. | % | 41915 |
Service Brake |
| Electromagnetic |
Drive |
|
|
Drive Motor rating S2, 60min. | kW | 0.65 |
Lift Motor rating S3 15% | kW | 0.84 |
Battery Voltage/ rated capacity (5h) | V/Ah | 24/60 |
Battery Weight | kg | 30 |
Battery compartment dimensions L/W/H | mm | 260 / 182 / 220 |
Battery Type |
| Maintenance free battery |
Others |
|
|
Type of drive control |
| DC |
Manufacturer |
| CURTIS |
Sound level at oprator's ear |
|
|
