Product Description
Being one of the renowned manufacturers, exporters and suppliers in this domain, we are offering our clients the finest quality Electric Pallet Truck. Designed for carrying heavy goods and material, this pallet truck is well-known between our clients due to its easy handling and smooth functioning. This pallet truck is manufactured by utilizing premium grade raw material with the help of pioneering technology as per the set industry quality standards. Moreover, this product can be avail from us at market leading prices.
Electric Pallet Truck Features:
- Offered pallet trucks are recognized for their impeccable performance and have robust construction
- These pallet trucks are known for less power consumption and negligible maintenance
- Our pallet trucks are easy to use, hence demanded by varied industries
- Moreover, these pallet trucks have compact design and are known for corrosion resistance
Advantages of Electric Pallet Truck:
- Electric Pallet Truck has Load Backrest with Keyless on-off toggle
- Drive-tow switch, Fork spread and lengths with Battery options
- Rugged steel construction with a durable powder-coat finish
- With 180° turning radius offers excellent Capability
- It cover huge distances in a short period of time
- Having Battery straps with Charger options and Casters
- Forks are 44 7/8in.L x 20 1/2in.W
- 3 5/8in. to 31 1/2in. lift range
- Standard pallet truck controls
Electric Pallet Truck Specifications:
- Capacity: 2.5ton 3ton, 3.5ton , 5ton
- Fork length: 1150mm/as per customer requirement
- Fork width 550mm /as per customer requirement
- Fork: 150mm
- Lower height: 90mm /as per customer requirement
- Raised height: 200mm /as per customer requirement
- Lift height: 115mm
- Lift: 10mm/Stroke
- Lower Speed: Continuously variable
- Wheel: 2nos 180x50mm steering nylon wheel with 6204zz double ball bearing
- "text-align: justify;">Handle: 3 lever position handle (lift/lock/release)
- Turning radius: 114 degree
- Structure weight: 85kgs to 100kgs
- 20' feet container: 180nos
Application:- Pharmaceuticals
- Bulk Drugs
- Paper Industries
- Cement Plants
- Ceramic & Sugar Industries
- Bottling Plants
- Steel and Pipe Plants
- Textile Units
- Chemicals
- Dyes
- Intermediate Units
Product details
Axle Loading, Laden Operator/Load Side | 600/1095 kg |
Axle Loading, Unladen Operator/Load Side | 170/25 kg |
Battery Voltage/ Rated Capacity | 24/60 V/Ah (5h) |
Battery Weight | 30 kg |
Fork Dimensions | 55/150/1150 mm |
Length to Face of Forks | 450 mm |
Load Capacity | 1500 kg |
Load Distance | 883/946 mm (Raised) |
Overall Width | 560 mm |
Overall Length | 1600 mm |
Service Weight | 195 kg (Incl. battery) |
Wheelbase | 1250 mm |
Operator Type | Walkie |
Lift Height Mm | 115 |
Brand | FIPL |
Drive Unit | Battery |
Load Center | 600 mm |
Model Name/Number | FIE-107 |
Usage/Application | Industrial |
